Technical Specifications
Electrical technical data
Power supply
12 ÷30 Vdc (polarity protected)
Power consumption
max. 0,7W
Accuracy (*)
(*) @25°C
± 0.5 °C (electronic section temperature -10÷50 °C)
Electronic board input Pt100
± 2 °C (electronic section temperature -10÷50 °C)
Electronic board input thermocouple
Output
Transistor PNP
Output NPN on request
refresh interval 1 second
max. pilot current 100 mA (with short-circuit protection)
Transistor NPN
Range configurations
It is possible set the device by EVOSTOPSET configuration kit (it is needed a PC with OS Windows).
Electronic board operating temperature
-25 ÷80°C
Sensing element operating temperature range
-50 ÷120°C
Resolution
0,1 °C
Sensing element
Pt100 Ω @ 0°C
Connector
Male M12 x 1 in accordance with IEC 61076-2-101 STANDARDS (output)
Process Connection
threaded 1/8" GAS CIL. acc. UNI-ISO 228
Connection body material
AISI 316
International protection marking (*)
(*) According to IEC 60529
IP67
