SEDATA060 - Rev. 0

RTR-501

Wireless communication datalogger with internal temperature sensor. Certificate DIN EN12830

Datalogger with internal sensor (-40÷80°C),LCD display and protection degree IP67 (immersion-proof); suitable for harsh environments such as inner parts of freezers or fridges, in dusty places or with high humidity etc... It can memorize up to 16.000 temperature points and re-transmit data in radiofrequency. Battery (standard 3,6V) can be simply substituted by the user.

  • Product Datasheet
  • Download

Technical Specifications

Parameter measured
temperature
Unit of measure
°C
°F
Measurement channel
1 ch
internal
Sensing element operating temperature range
-40 ÷80°C
response time (90%)
tempo costante termica:
circa 15 minuti
response time (90%):
circa 35 minuti
Accuracy (*)
(*) @25°C
media ±0,5 °C
Resolution
0,1 °C
Memory capacity
16.000 letture
Registration interval
it is possible to choose between 15 intervals:
1, 2, 5, 10, 15, 20, 30 seconds
1, 2, 5, 10, 15, 20, 30, 60 minuts
Registration modality
Endless ( Overwrite oldest data when capacity is full )
One Time ( Stop recording when capacity is full )
Display indication
current reading
registration state
battery state warning
unit of measure
Power supply
batteria al litio LS14250
alimentazione esterna (kit adattatore RTR-500A2, venduto separatamente)
Battery life
circa 10 mesi
Battery life varies depending upon multiple factors including ambient temperature, recording interval, frequency of communication, and battery performance. All estimates are based on operations carried out with a new battery and are in no way a guarantee of actual battery life.
Communication interface
wireless
ottica (protocollo proprietario)
Download dei dati via wireless
circa due minuti per un' unità con memoria piena
è richiesta la stessa quantità di tempo per ogni ripetitore aggiuntivo
Download dei dati via ottica
circa 160 secondi
Standard wireless
ETSI EN 300-220
frequenza da 869,7 a 870 MHz (selezione tra 11 canali)
potenza emissione RF di 5 mW
Transmission range
circa 150 metri in linea d'aria e in assenza di ostacoli
Dimensions
62 mm x 47 mm x 19 mm
Lunghezza antenna
24 mm
Weight
circa 56 gr (inclusa batteria)
International protection marking (*)
(*) According to IEC 60529
IP67
resistente alle immersioni
environmental conditions
-40 ÷80°C
Unità base compatibili
RTR-500
RTR-500AW
RTR-500NW
RTR-500DC
RTR-500MBS-A
Packaging
lithium battery (LS14250)
user's manual (warranty included)
Option
attacco a parete TR-05K3 (cod. SEDATA00K3)
kit per batterie ad elevata capacità RTR-500B1 (cod. SEDATA059)
kit per alimentazione esterna RTR-500A2 (cod. SEDATA058)
set di manutenzione TR-00P1 (cod. SEDATA00P1)
see Accessories for more information
Note
wireless communication is not possible with temperatures below -30 ° C
