Technical Specifications
Parameter measured
temperature
humidity
Unit of measure
°C
°F
%
Measurement channel
1 ch
external
Sensing element operating temperature range
0 ÷55°C
Sensing element humidity operating range
10 ÷95 %
response time (90%)
response time (90%):
circa 7 minuti (temperatura e umidità)
Accuracy (*)
(*) @25°C
temperatura: ±0,5°C
umidità: ±5 % UR (a 25 °C con 50 % UR)
Resolution
0,1 °C
1 % UR
Memory capacity
8,000 sets of readings (a data set consists of a multiple channel reading)
Registration interval
it is possible to choose between 15 intervals:
1, 2, 5, 10, 15, 20, 30 seconds
1, 2, 5, 10, 15, 20, 30, 60 minuts
Registration modality
Endless ( Overwrite oldest data when capacity is full )
One Time ( Stop recording when capacity is full )
Auto-download interval
it is possible to choose between 15 intervals:
1, 2, 5, 10, 15, 20, 30 minute
1, 2, 3, 4, 6, 12, 24 hours
OFF (no Auto-download)
Display indication
current reading
registration state
battery state warning
unit of measure
Power supply
alkaline battery AA (LR6)
through the computer's USB port
network adapter model AD-05C2
Battery life
with LAN comunication:
From about 10 days to 1 years (about 10 days when the auto-download interval is 1 minute, 7 year when it is 1 hour and 1 year when it is 12 hours or more)
without LAN comunicaztion:
about 1 year
Battery life varies depending upon multiple factors including ambient temperature, recording interval, frequency of communication, and battery performance. All estimates are based on operations carried out with a new battery and are in no way a guarantee of actual battery life.
Communication interface
LAN wireless
USB
Standard wireless
IEE 802.11 b
security: WEP (64 bit / 128 bit), WPA-PSK (TKIP), WPA2-PSK (AES)
WPS 2.0: press the configuration key
protocol: Http, DHCP, DNS
WPS function can be used when WEP (64 bit / 128 bit) or WPA-PSK (TKIP) are set as Access Point. If you want to use the WPS function, select WPA2-PSK (AES) or remove the wireless network security
Dimensions
58 mm x 47 mm x 26 mm
Weight
about 55 gr
Operative condition
Temperature: -10 ÷ 60 °C
Humidity: 90 % RU or less (no condense)
Packaging
temperature and humidity sensor THA-3001 (cod. SEDATA130)
alkaline battery AA (LR6)
Label to write device code
user's manual (warranty included)
Compatible operating systems
software TR-7wf for Windows (PC):
Windows® 7 (64 bit)
Windows® 7 (32 bit)
Windows® 10 (64 bit)
Windows® 10 (32 bit)
Windows® 8 (64 bit)
Windows® 8 (32 bit)
Windows® Vista (32 bit with SP1 o higher, T&D Data Server is not compatible)
Thermo Web application (mobile devices):
Android (version 2.2 or later)
iOS (version 7.1 or later, compatible with iPhone, iPad and iPod touch)
Option
sensore di temperatura e umidità THA-3151 (cod. SEDATA068)
temperature and humidity sensor SHA-3151 (cod. SEDATA144)
temperature and humidity sensor extension TR-1C30 (cod. SEDATATR1C30)
network adapter model AD-05C2 (cod. SEDATA125)
wall mount TR-07K2 (cod. SEDATA053)
see Accessories for more information
Note
wireless communication is not possible with temperatures below -30 ° C
